- Short learning curve
- High safety
- Effective shattering of calcification
- Easy operation
| Catalogue Number | Balloon Specification | Sonication Pressure | Nominal pressure | Rated Burst Pressure kPa(atm) | Maximum Guide Wire O.D. (inch) | Compatible Catheter | Catheter Effective Length (mm) | Maximum Number of Pulses | Number of Cycles | Number of Pulses in a Single Cycle |
| LPCAW25012 | 2.5*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW27512 | 2.75*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW30012 | 3.0*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW32512 | 3.25*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW35012 | 3.5*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW37512 | 3.75*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
| LPCAW40012 | 4.0*12 | 4atm | 6atm | 12atm | 0.014” | 6F | 1350mm | 80 | 8 | 10 |
*Product registration and availability vary by country. For more information on product availability, please contact our sales.
-
An electrode is used to generate high-voltage spark discharge in water, and the surrounding water medium is immediately evaporated explosively due to the electro-hydraulic effect, thus forming a rapidly expanding plasma to generate electric pulses in the surrounding liquid.
-
Sound pressure standardization test at 4atm, demonstrating effectively shattering calcification.
- High-definition large screen, with fulldisplay, and high endurance
- tightly wrapped with guide wire, to avoid fish mouth effect
- (made of PEBAX), with superior passability, flexibility, and retraction
- The balloon is equipped with platinumMarker rings at both ends to assist inpositioning
- Design of electrodes in parallel, ensuring more stable discharge
- Uniform sound pressure distribution, giving consideration to safety and effectiveness
- One click start, continuously triggering pulses, easy to operate
- Sharp and anti-friction blades, balance cuttingforce and flexibility
- Blades Working height is only 0.13mm, which could avoid blood vessel perforation
- Pre-made longitudinal neat blades, which could reduce the risk of intimal disordered tearing
- Sharp and anti-friction blades, balance cuttingforce and flexibility
- lmprove crossability
- Optimize retraction
- lmprove crossability
- Optimize retraction
The surgical success rate is 100%, and the 95% CI lower limit for the surgical success rate is greater than the target value (86%).
This product is presented for academic exchange purpose only and is not intended for sale within European Union.
